Load Cell, Load Cell 1-50KG Module Weight Sensor Electronic Scale Aluminum Alloy Weighing Pressure Sensor for Lab Mini Type for Hopper Weight High Pressure Tension Weighing(10KG) (10kg A)

A load cell is actually a device that converts a mass signal into a measurable electrical signal output. When using a sensor, you should first consider the actual working environment in which the sensor is located. This is crucial to the correct selection of the weighing sensor. It is related to whether the sensor can work normally, its safety and service life, and even the reliability and safety of the entire weighing instrument. Product Paramenters Capacity: 1-50kg Output sensitivity: 1.0±0.2MV/V Zero point output: ±0.5%F.S Nonlinear: 0.05%F.S Hysteresis: 0.05%F.S Repeatability: 0.05%F.S Creep(30 minutes): 0.05%F.S Input resistance: 1000±10% Output resist-ance: 1000±10% Opearting temperature range: -10-+50 Zero tempearture drift: 0.05%F.S/10 Sensitivity temperature drift: 0.05%F.S/10 Insulation resistance: 2000M Safe overload: 120%F.S Extreme overload: 150%F.S Excitation voltage: 3-10V Comprehensive accuracy: 0.3%F.S Mode of connection Input+ : Red, Input- : Black, Output+ : Green, Output- : White

• Easy to use.
• Long service life.
• Fine workmanship and good performance.
• Made of quality materials,safe,environmentally friendly,.
• price-performance ratio,save you more money.
